Getting started with navigation

Precautions for safe driving

Please observe and comply with local traffic rules and regulations.

The route displayed for destination guidance is a reference and the route guidance will take you to the vicinity of your destination. The highlighted route is not always the shortest distance, the least congested, and in some cases, might not be the fastest route.
Road, name, POI and speed limit may not always been completely updated.
The car position mark does not indicate your exact location. This system uses GNSS information, various sensors, and road map data to display the current position. However, errors in displaying your location may occur if the satellite is transmitting inaccurate signals or less than two satellite signals are received. Errors that occur in such conditions cannot be corrected.
The position of the vehicle within the navigation may differ from your actual location depending on various reasons, including the satellite transmission state, vehicle state (driving location and conditions), etc. Additionally, the car position mark may differ from the actual position if the map data is different from the actual road landscape, such as changes due to the construction of new roads. If such differences occur, driving for a short period of time will automatically correct the position of the vehicle through map matching or GNSS information.

What is GNSS?

The GNSS(Global Navigation Satellite System) is a satellite-based navigation system made up of a network of 32 satellites placed into orbit by the Global Positioning System (GPS) of U.S.A, GLONASS of RUSSIA, etc.

GNSS works in any weather conditions, anywhere in the world, 24 hours a day.

There are no subscription fees or setup charges to use GNSS.

About satellite signals

Your unit must acquire satellite signals to operate. If you are indoors, near tall buildings or trees, or in a parking garage, the unit cannot acquire satellite signals.

Acquiring satellite signals

Before the unit can determine your current position and navigate a route, you must do the following steps:

Go outside to an area free from tall obstructions.
Turn on the unit. Acquiring satellite signals can take a few minutes.

Operating navigation screen

The navigation system displays various information on the map screen.

Map screen

Press [MAP] or [NAV] > [Map] to access the map screen.

Displays the distance to next turn, maneuver at next turn and serial turn. Press to repeat voice instructions.

2 [/ ] button

[ / ] button to set the zoom level on the map screen.

3 Remaining distance display

Displays the remaining distance to the destination.

4 [] button

Displays functions in the sub menu.

5 Map view button

Changes the map view perspectives.

Press [] repeatedly to switch them.

2D North-up: The map always points north regardless of the direction that the vehicle is moving.
2D Heading-up: The map always displays the vehicle’s direction as proceeding towards the top of the screen.
3D Heading-up: The map always displays the basic outline and details of the surrounding roads and general area.

6Street/city information display

Displays the current street information or city information. Press to switch the display.

Displays speed limit information on the road.

8 [] button

Click to display extra information, next turn or the turning junction. The button will be disabled when there is no extra information to show.

9 Vehicle position mark

Displays current vehicle position and direction.

The mark is green: GPS signal good.
The mark is Yellow: GPS signal weak.
The mark is red: GPS signal lost.
The mark is grey: When simulating.

10 Arrival time display

Displays the estimated time until the arrival at the destination.

11 [] button

Displays GPS receiver status. Press to check GPS information.

The status is green: GPS signal good.
The status is red: GPS signal lost.

12 Clock display

Displays the current time.

Displays the instruction for current turn.

Press to access the turn list.

Quick menu

Press [] on the map screen.

Press the desired item.

[]: Press [] to open or close the sub menu.
[]: Cancels the route when it is set.
[]: Moves to the home. Enable the button by saving a location as favorite and set as home.
[]: Moves to the sound settings screen.
[]: Finds a destination by searching for POI near the current position.
[]: Starts simulation when the route is set.

Sound setting for navigation

Press [] on the quick menu.

Set the guidance volume of navigation by pressing [a] / [d], then press [Apply].

, Note

You can access the sound setting menu for navigation by pressing [b] > [Sound].

Scrolling the map screen

Drag and drop the map screen to the desired direction, then touch the desired point.

Information on the point is displayed on the screen. It can be used as an electronic map.

1 [] button

Displays compass. Press to change the orient of map.

2 [] button

Returns to current vehicle position.

3[/ ] button

[ / ] button to set the zoom level on the map screen.

4 [] button

Moves to the main menu of navigation.

Displays scale ruler.

6 Selected location mark

Displays selected location (road or POI) with information panel about it.

Main Menu

Press [NAV] or touch anywhere on the map screen.

Press the desired option.

[Find]: Finds a destination by using the [Find] menu.
[Map]: Moves to the map screen or navigation/free run screen.
[Route]: Access to check information of current route, or set your route options.
[b] (Settings): Changes the software settings of navigation.
[] (My Data): Maintains user specific information like [My Favorite], [My Itinerary], [My Trail], and [Clear Data].
[] (Information): Displays [GPS], [Statistics] and information about the navigation system.

Sub-menu operation

All sub-menus of navigation have the following features at the top of the screen.

[]: Moves to navigation/free run screen.
[]: Moves to the main menu.
[]: Moves to the previous screen.
