Name of Each Component

Head unit

Head unit functions may vary for each model.

POWER PUSH or PWR / Volume knob

• Press to turn the power on.
• When power is on, press and hold to turn power off.
• When power is on, press to turn Audio off.
• Turn left/right to control volume.

HOME button (AV only)

• Press to go to the home screen.

PHONE button (AV only)

• Press to go to the phone screen.

MAP button (AVN only)

• Press to display the map screen of the current location.

NAV button (AVN only)

• Press to move to the Navigation menu screen.

b (Reset hole)

• Press with a thin object to reset the unit when it does not operate normally.

K (Custom button)

• Press to move to the [Custom button] menu. After setting a desired function, press to use the desired function.

A SEEK/TRACK D (S/W) button

When it is pressed for a short time.

• Radio mode: Plays previous/next available frequency or station.
• Media mode: Plays previous/next file.

When it is pressed and held

• Radio mode: Plays previous/next available frequency or station.
• Media mode : Rewinds or fast forwards the file.

RADIO button

• Press to go to the radio screen.

MEDIA button

• Press to go to the available media.

SETUP button

• Press to go to the settings screen.

Tune/Enter knob

• In Radio mode, turn left/right to change the frequency or station.
• In Media mode, turn left/right to change file and press to select the desired file.

Steering Wheel Remote Control

Steering wheel remote control functions may vary for each model.

C / MODE button

• Each time this button is pressed, the Radio or Media mode is changed.
• If the media is not connected, it is changed in the order FM > AM > FM.
• When it is pressed and held, move to Advanced settings "Steering wheel MODE button".

W/S button

When it is pressed for a short time

• Radio mode: Plays previous/next Favourites.
• Media mode: Plays previous/next file.

When it is pressed and held

• Radio mode: Plays previous/next available frequency or station
• Media mode: Rewinds or fast forwards the file.

i (Voice Recognition button)

• Press to switch to voice recognition mode.
• To cancel it, press and hold the button again.

W button

Press to operate Bluetooth hands-free function.

• Press to accept a call.
• Press to make a call from last calls.
• Press and hold for redialing.

Z button

• Press to end the phone call during a call.
• Press to reject the call in the incoming call screen.
• Press to end Voice memo recording.

J / I button

• Increases or decreases the volume level.

d (Mute)

• Press to mute the sound. (It will be paused in some media modes.)
