Getting started with navigation

Precautions for safe driving

Please observe and comply with local traffic rules and regulations.

• The route displayed for destination guidance is a reference and the route guidance will take you to the vicinity of your destination. The highlighted route is not always the shortest distance, the least congested, and in some cases, might not be the fastest route.
• Road, name, POI and speed limit may not always been completely updated.
• The car position mark does not indicate your exact location. This system uses GNSS information, various sensors, and road map data to display the current position. However, errors in displaying your location may occur if the satellite is transmitting inaccurate signals or less than two satellite signals are received. Errors that occur in such conditions cannot be corrected.
• The position of the vehicle within the navigation may differ from your actual location depending on various reasons, including the satellite transmission state, vehicle state (driving location and conditions), etc. Additionally, the car position mark may differ from the actual position if the map data is different from the actual road landscape, such as changes due to the construction of new roads. If such differences occur, driving for a short period of time will automatically correct the position of the vehicle through map matching or GNSS information.

What is GNSS?

The GNSS(Global Navigation Satellite System) is a satellite-based navigation system made up of a network of 32 satellites placed into orbit by the Global Positioning System (GPS) of U.S.A, GLONASS of RUSSIA, etc.

GNSS works in any weather conditions, anywhere in the world, 24 hours a day.

There are no subscription fees or setup charges to use GNSS.

About satellite signals

Your unit must acquire satellite signals to operate. If you are indoors, near tall buildings or trees, or in a parking garage, the unit cannot acquire satellite signals.

Acquiring satellite signals

Before the unit can determine your current position and navigate a route, you must do the following steps:

1. Go outside to an area free from tall obstructions.
2. Turn on the unit. Acquiring satellite signals can take a few minutes.

Viewing map screen

Press [MAP] button to access the map screen.

If you press the map anywhere during navigation, the map stops following the current position and control buttons appear to help you modify the map view.

1 Changing 2D, 3D, or 2D North up views

Switch between the 3D perspective, 2D Heading up, and 2D North up map view modes. In Heading up mode the map is rotated so its top always points in the current driving direction. This is the default orientation in 3D map view mode. In North up mode, the map faces North.

2 Zooming in and out

Map scaling has a limit in 3D map view mode. If you zoom out further, the map switches to 2D view mode.

Press once to modify the view in a large step, or press and hold the button to modify it continuously and smoothly.

3 Returning to the previous screen

Press the Back button to return to the previous screen. You can also press and hold this button to quickly return to the navigation view from any other screen.

4 Selecting a destination

Select the cursor location as a new destination. The route is automatically calculated.

5 Checking location information

The location of the cursor can be used as the destination of the route or a new Alert Point.

The top section of the navigation view shows information about the selected point.

6 Selecting additional options

Open a list of additional features like saving a location, or searching for places around the cursor.

7 Rotating left and right

Changes the horizontal view angle of the map.

Press once to modify the view in a large step, or press and hold the button to modify it continuously and smoothly.

8 Checking the compass

The direction of the compass shows North.

Operating navigation screen

The navigation system displays various information on the map screen.

1 Next turn

It shows the type of the next manoeuvre and its distance.

2 Second next turn preview

It shows the type of the second next manoeuvre if it is near the first one.

3 Speed limit warning

It shows the current speed limit of the road.

4 Data fields

• The estimated time of the arrival at the destination.
• The remaining time of the trip.
• The remaining distance to the destination.

You can change the default values by pressing and holding the area where the data fields appear.

5 Current position maker

The current position is displayed as a blue arrow arrow by default. When there is no GPS position, the current position marker is transparent and it shows your last known position.

6 Street name

It shows the current street name.

7 Navigation menu

The menu button appears when the navigation view is displayed. Press it to open the navigation menu.

8 Planned route

The planned route is displayed as an orange line.

9 Sound settings

Adjust the different sound volumes.

10 Next street

It displays the name of the next street.

Using the navigation menu

On the navigation view, press [] to open the navigation menu.

You can see the following menu options when you are navigating without a planned route:

1 New Route

Select your destination by entering an address or its coordinate, or by selecting a Place, a Saved location, or a saved route. You can also look up your recent destinations from the History.

2 Multipoint Route

Build your route from one or more route points. You can also plan a route independently of your current GPS position by setting a new starting point.

3 Useful Information

Access additional options and check navigation-related information.

4 Settings

Customise the way the navigation software works.

5 Update

Visit https://www.naviextras.com to get additional content, such as new maps or useful applications.

6 About

See information about the navigation software.

With a planned route, the following menu options are also available:

7 Add Waypoint

Add an intermediate destination to your route.

8 Detours & Alternatives

See route alternatives to avoid parts of the route, or to avoid a specific road from your planned route.

9 Route Summary

View the route in its full length on the map and check route parameters and route alternatives.

Press [] to access additional options, like Route Preferences.

10 Delete Route/Route Summary

• Delete Route: Delete your route.
• Delete Waypoint: Delete the next waypoint or the whole route.

11 K

Move to the Saved Location menu screen.

12 3D

Select 3D, 2D, 2D(North) UI mode.

13 U

Pause Gdance.
